WG68 Tri-angle (20.60.85 Degree)

  • WG68 Tri gloss meter(20° 60° 85°)
  • WG68 Tri gloss meter(20° 60° 85°)
  • WG68 Tri gloss meter(20° 60° 85°)
  • WG68 Tri gloss meter(20° 60° 85°)
  • WG68 Tri gloss meter(20° 60° 85°)
  • WG68 Tri gloss meter(20° 60° 85°)
WG68 Tri gloss meter(20° 60° 85°)WG68 Tri gloss meter(20° 60° 85°)WG68 Tri gloss meter(20° 60° 85°)WG68 Tri gloss meter(20° 60° 85°)WG68 Tri gloss meter(20° 60° 85°)WG68 Tri gloss meter(20° 60° 85°)

WG68 Tri gloss meter(20° 60° 85°)

  • 1. One button to complete triangle measurement: one operation can complete three angle measurement; Measuring light incident angle meet ISO 2813 three measuring light incident angle. Three incident an
  • 2. Optional angle mode: choose measuring angle or angle combination according to user needs;
  • 3. Manually entering standard samples gloss data;
  • 4. Three angle can store 50000 testing records, storage structure is: 100 prototypes, each prototype with 500 testing data.
  • Product description: WG68 gloss meter is produced according to the national verification regulation of JJG696 standard, adopt long life light source, good repeatability, small volume, high precision and good stability. It
  • INQUIRY

WG68 gloss meter is produced according to the national verification regulation of JJG696 standard, adopt long life light source, good repeatability, small volume, high precision and good stability. It is mainly used coatings, printing ink, paint, paint, wood, marble,   granite, bo to change polishing brick, brick of pottery and porcelain, plastic, paper, metal and non-metallic materials to the surface of the mirror gloss measurement.


Gloss meter WG68 functional description

(1) One button to complete triangle measurement: one operation can complete three angle measurement; Measuring light incident angle meet ISO 2813 three measuring light incident angle. Three incidenct angle of mirror gloss meter is 20 ° 60 ° 85 ° respectively;

(2) Optional angle mode: choose measuring angle or angle combination according to user needs.

(3) Manually entering standard samples gloss data;

(4) Humanized design, good man-machine communication interface;


Attachment description

(1) Power adapter: standard + 5V, 2A external power supply;

(2) Standard board: provide calibration criterion.

(3) USB cable: connect instrument to PC.


Standard for gloss meter

(1)ISO2813ISO7668

(2)ASTM D523ASTM D2457

(3)GB/T 9754GB/T 13891GB/T 7706GB/T 8807




WG68 specification

Specification

Unit

Triangle Gloss Meter

Measuring Angle

degree

20° 60° 85°

Measuring Range

GU

20°:0-2000

60°:0-1000

85°:0-160

Measuring Spot

mm

20°: 10x10

60°:9x15

85°:5x38

Accuracy

GU

0-1000:0.1  1000-2000:1

Repeatability

GU

0-100:0.2 >100:0.2%

Indication Error

GU

±1.5

Zero Error

GU

0.2

Working Temperature Range

10℃ - 40℃

Storage Temperature Range

-10℃ - 70℃

Humidity Range


Relative humidity less than 85%,without condensation

Power Adapter


Section 2 5 alkaline batteries/power adapter

Volume

mm

159x49x72

Weight

g

500
