WN700D

  • 1.Adopts advanced electronic circuit system and perfect optical system
    2.High precision, good stability and strong anti-interference
    3.Multi aperture design,large application
    4. Rechargeable, high capacity lithium battery.
    Product description: WN700D with competitive price, high quality,high accuracy,easy to operate, easy to understand, affordable and so on. .
  • 留言咨询

WN700D is a cost-effective spectrophotometer designed by Wave Optoelectronics Co., Ltd. This spectrophotometer adopts advanced electronic circuit system and perfect optical system, which has the advantages of high precision, good stability and strong anti-interference. It provides great reliability and convenience for color control in all walks of life.



Model

WN700D(Single Caliber)

WN700S(Switchable Caliber)

Geometric Conditions

d/8

Color Space

CIEL*a*b*、CIEL*C*h、Yxy

CIEL*a*b*、CIEL*C*h、CIEL*u*v*、Hunter LAB、CIEXYZ、Yxy、Reflectivity、CMYK、YI Yellowness、Ganz、ISO Brightness(R457 Whiteness)、Taube Whiteness、z Whiteness、sRGB

Standard Light Source

A、C、D50、D65、F2(CWF)、F12(U30)

A、C、D50、D55、D65、D75、F1、F2(CWF)、F3、F4、F5、F6、F7、F8、F9、F10、F11(TL84)、F12(U30)

Light Source

Combined LED

Color Diff. Formula

△E*ab、△E*Ch

△E*ab、△E*Ch、△E*uv、 △E*Hunter、△E*cmc(2:1)、△E*cmc(1:1)、△E*94、△E*00、△E*sRGB、△E*BFD、△E*FMCII

Measuring Caliber

Facula 4mm(Caliber Φ6mm)、 Facula 8mm(Caliber Φ11mm)、Facula 16mm(Caliber Φ16mm)

Switchable: Facula 4mm(Caliber Φ6mm)& Facula 8mm(Caliber Φ11mm)

Single: Facula 16mm(Caliber Φ16mm)

SCI/SCE

SCI

SCI/SCE

Sensor Array

Line array CMOS@256 pixels

Spectral Way

Concave diffraction grating

Observer

CIE10°(1964)、CIE2°(1931)

Wavelength coverage

400nm~700nm

Wavelength interval

10nm

Measuring interval

2.5 Second

Reflectance range

0%-200%

Repeated accuracy

△E<0.07 (take the deviation average after 30 times measuring the whiteboard)

△E<0.05 (take the deviation average after 30 times measuring the whiteboard)

Table Difference

△E<0.4(Measure the RAL 12-color blocks)

△E<0.3(Measure the RAL 12-color blocks)

Light source life

More than 50,000 hours

Battery power

Measuring more than 10000 times

Display screen

TFT true color 2.8inch@(16:9)

Data storage capacity

Storage Standard 100 groups



Sample 16,000 groups

Operating temperature

0℃-40℃(32℉-104℉)

Storage temperature

-20℃-50℃(-4℉-122℉)

Working humidity

Relative humidity less than 85%,without condensation

G.W

1.5kgs

1.5kgs

Size of exterior package

28*19*11cm

28*19*11cm

Standard accessories

Power adapter, standard white board, standard black cavity, lithium battery, specification, PC software

Optional accessories

Software(Advanced Version), Micro printer, Locating block
